for the first time in china, we proposed the intelligent oil extraction system with the technology of the sensorless vector control and direct drive device without reducer. after ten years of experiment and verification, the product has been finalized and can realize mass production integration. the espcp system developed and integrated by us has become a revolutionary product to replace the traditional manual lifting products.
after the pump unit of the espcp system is lowered down into the well, the power is transmitted through the power cable to the submersible motor under the well to drive the progressive cavity pump(pcp) and the fluid in the well is then raised up onto the ground with the pressure boost of pcp.
during operation, the electricity is transmitted via the submersible cable from the servo control system on the ground to the purpose-designed permanet magnetic synchronous motor in the down-hole for stepless speed regulation so that the motor can run at a low speed but a high torque output, driving pcp to extract oil through the protector and the shaft coupler.
no need for pumping unit body and sucker rod, small footprint, no leakage at the wellhead, no noise, high safety factor
no need for pumping unit ground equipment and sucker rods, saving a lot of steel
avoiding the breakage of the column, the wear of the tube and the loss of power, eliminating the cost of civil works
high reliability and low maintenance costs
the product has been pumped down in daqing oilfield and shengli oilfield, and has been running stably for more than 300 days.
the first step in oil exploration is petroleum seismic exploration. the purpose is to find out the underground geological structure and lithology evolution process, find oil and gas enrichment zones, provide oil and gas reserves, structural traps, drilling well locations, and cooperate with oilfield development and production. task. at present, petroleum exploration methods mainly include geological methods, drilling methods, chemical exploration methods, and physical exploration.
